– 100Base-TX to 100Base-FX Media Converter (Single mode 1310nm) – 60km.
– Fiber-optic speeds are critical to success, but twisted-pair cabling can only go so far. Using D-Link’s converters you can change a twisted-pair Fast Ethernet connection into a single-mode or multi-mode fiber connection that can go much farther. Converters for distances of anywhere from 2 km to 60 km allow you to optimize your selection.
Media converter D-Link DMC-920R
– A pair of one-channel single fiber is used for media conversion between 10/100BASE-TX and 100BASE-FX.
– Two different transmitting wavelengths, one wavelength with bi-directional for both transmit and receive.
– This media converter provides 1310 micron for TX, 1550 micron for RX.
– Fiber cable support is 9/125um, 10/125um single-mode fiber, maximum 20 km cable distance.
10/100Mbps Multi-mode Media Converter TP-LINK MC100CM
– Complies with 802.3u 10/100Base-TX, 100Base-FX standards
– Link Fault Passthrough and Far End Fault minimize the loss caused by link failure timely
– Provides switch configuration of Half-Duplex / Full-Duplex transfer mode for FX port
– Extends fiber distance up to 2km
– Auto negotiation of 10/100Mbps and auto MDI/MDIX for TX port
– Provide switch configuration of Half-Duplex / Full-Duplex transfer mode for FX port
Gigabit Single-mode SFP Media Converter TP-LINK MC220L
The MC220L is a media converter designed to convert 1000BASE-SX/LX/LH fiber to 1000Base-T copper media or vice versa. Designed under IEEE802.3ab 1000Base-T and IEEE802.3z 1000Base-SX/LX/LH standards, the MC220L is designed for use with multi-mode/single-mode fiber cable utilizing the LC-Type connector. It works at 850nm on both transmitting and receiving data when adopting multi-mode fiber and 1310nm on both transmitting and receiving data when adopting single-mode.
100Base-TX to 100Base-FX (LC) Single-mode Media Converter D-Link DMC-F20SC-BXU/E
D-Link’s Standalone Media Converters turn an Ethernet connection into fiber, allowing for ultra-fast long distance connections. Installation of a Standalone Media Converter is simple, and allows you to tap into fiber speeds with ease. Instead of requiring an investment in an entire chassis, the standalone series is able to provide the same high-quality conversion on a unit-by-unit basis. The standalone nature of these means that you can use save space and cut costs while still extending your network over long distances up to 60 km on a fiber-optic line. In addition to all models supporting 10/100 Mbps Half/Full-duplex, the DMC-G01LC also allows for 1000 Mbps Full-Duplexing, letting you truly maximize your network’s potential.
